Arche
World’s most cost-effective femtosecond OEM fiber laser component
- Wavelength
- 1550 nm ± 5 nm
- Pulse Duration
- ≤ 250 fs
- Repetition Rate
- 65 MHz ± 2 MHz
A suite of ultra-fast OEM fiber laser component with 65 MHz ± 2 MHz, centered at 1550 nm ± 5 nm, delivering ≤ 250 fs. Arche becomes a workhorse tool for many research and industrial applications requiring reliability and affordability.
FYLA is ISO 9001:2015 certified, ensuring quality and consistency across the design, manufacturing, and commercialization of our technologies.
a { text-decoration: none; color: #464feb; } tr th, tr td { border: 1px solid #e6e6e6; } tr th { background-color: #f5f5f5; }
FYLA LASER S.L., within the framework of the ICEX Next Programme, has received support from ICEX and co-financing from the European Regional Development Fund (ERDF). The aim of this project is to contribute to the company’s international growth and the development of its business environment.
The optical emission from this OEM laser module may reach Class 3B levels. It is the responsibility of the integrator to implement all safety measures required for the final system class.
Technical specifications
| Central Wavelenght | 1550 nm ± 5 nm |
|---|---|
| Spectral Bandwidth | > 15 nm |
| Repetition Rate | 65 MHz ± 2 MHz |
| Average Power | ~ 25 mW |
| Pulse Duration | ≤ 250 fs |
| Polarization | Linearly Polarized |
| Output Port | Single mode fibre. 0.30 m length (customizable) |
| Optical Output | FC/PC connector |
| Synchronization / Connections | Optical Signal |
| Pulse Energy | 300 - 600 pJ |
| Peak Power | 1 - 3 kW |
| Spatial Mode Quality (M²) | < 1.2 |
| Cooling | Air cooling |
| Power Requirements | 110 V - 220 V / 50 Hz-60 Hz |
| Operating Temperature | 20 - 30 ºC |
| Storage Temperature | 0 - 60 ºC |
| Dimensions | 200 x 120 x 53 mm (WxDxH) |
